DB-957s BOAS Dynamic Microphone
Frequency Response : DB-957s
Close Response : 25 to 22,000 Hz
Far Response : 50 to 22,000 Hz
Polar Pattern : super cardioid
Open Circuit Voltage : 3.3 mv/pascal
Sensitivity : -51 dB
Dynamic Range : 141 dB
Equivalent
Output Noise : 14 dB
Impedance : 158 ohms balanced
Weight : 7.0 ounces (218 grams)
Dimensions,
Height : 181mm
Diameter : 56mm
Shank : 25 mm

MODEL : DB-957s

제품 주문제작

DB-957 BOAS Dynamic Microphone
Frequency Response : DB-957
Close Response : 25 to 22,000 Hz
Far Response : 50 to 22,000 Hz
Polar Pattern : super cardioid
Open Circuit Voltage : 3.3 mv/pascal
Sensitivity : -51 dB
Dynamic Range : 141 dB
Equivalent
Output Noise : 14 dB
Impedance : 158 ohms balanced
Weight : 7.0 ounces (218 grams)
Dimensions,
Height : 181mm
Diameter : 56mm
Shank : 25 mm

MODEL : DB-957

제품 주문제작

DB-857 BOAS Dynamic Microphone
Frequency Response : DB-857
Close Response : 25 to 22,000 Hz
Far Response : 50 to 22,000 Hz
Polar Pattern : super cardioid
Open Circuit Voltage : 301 mv/pascal
(where 0dB=1 mW/10 dynes/㎠)
Sensitivity : -50 dB
Dynamic Range : 140 dB
Equivalent
Output Noise : 14 dB
Impedance : 150 ohms balanced
Weight : 7.1 ounces (218 grams)
Dimensions,
Height : 181mm
Diameter : 52mm
Shank : 25mm

MODEL : DB-857

제품 주문제작

DB-58s BOAS Dynamic Microphone
Frequency Response : DB-58s
Close Response : 25 to 20,000 Hz
Far Response : 50 to 20,000 Hz
Polar Pattern : super cardioid
Open Circuit Voltage : 301 mv/pascal
(where 0dB=1 mW/10 dynes/㎠)
Sensitivity : -48 dB
Dynamic Range : 140 dB
Equivalent
Output Noise : 16 dB / (0 dB=00020dyne/㎠)
Impedance : 150 ohms balanced (Lo-z)
Weight : 7.7 ounces (218 grams)
Dimensions,
Height : 7.12 (181mm)
Diameter : 2.05(52mm)
Shank : 0.80(20mm)

MODEL : DB-58s

제품 주문제작
